The XYZ CARGO TRIKE is a three-wheeled cargo cycle for transporting people and heavy loads in a stable way.

Unlike traditional three-wheeled cargo cycles, the XYZ CARGO TRIKE features Ackermann-steering. This makes the XYZ CARGO TRIKE easy to control and manoeuvre even at higher speeds.

Ten years of development have made the XYZ CARGO TRIKE a state-of-the-art cargo cycle , that not only lives up to any other commercial cargo cycle, but also stays an open source concept you can modify yourself.

Dimensions: 208(L)x94(W)x105cm(H)

Box Dimensions: 55cm(W)× 80cm(L) x 35cm(H)

Weight: 34kg (plus 3.8 kg for electric motor system not including battery)

Loading capacity: 150kg plus driver weight

Driver height: 150-210cm

Please Note: components could change (similar or better quality) depending on supply chain

Bottom Plating: Transparent Polycarbonate Sheet

Side Plating: Aluminium Composite sides in White or Transparent Polycarbonate Sheet

Frame: Anodised aluminium frame; stainless bolts and self-securing nuts; anti-corrosion washers

Gears: 8 speed Claris with 12-25 8 speed cassette and a Shimano 8-speed trigger shifter.

Motor System: 250W Promovec e-cargo rear hub motor with 326WH battery; led button controller

*Complies to BS EN 15194:2017 for electric assist motors*

Front Wheels: Halo T2 20” rims, Sapim Leader Spokes, 90mm Sturmey Archer SD-XL drum brakes with synchronous braking.

Rear: Promovec Cargo Line Hub; Halo T2 26” rims; Sapim Leader Spokes; Avid BB5 Mechanical Disc brake

Tyres: Schwalbe puncture resistant delta 20’x1.75(Front); Marathon plus 26” x 1.75(rear)

Seat: Comfort saddle; adjustable seatpost

Pedals: XLC city/comfort pedal

Non-Electric Version:

Rear: Alfine 8-Speed Internal Hub; Halo T2 26” rims; Sapim Leader Spokes; Avid BB5 Mechanical Disc brake

Front Light – E-Bike 6V: £65 (Includes wiring)

Front Mudguards: £45

Battery Upgrade to 626wh: £200

9-speed upgrade: £120

Rear Brake Upgrade to Avid BB7: £30

Disc Brake Up-grade Front Wheels:£220

Coloured or Custom panels: Contact us for a quote.

Rain Cover: £90

ADD-ONS: All XYZ TRIKEs are Modular and customisable.

Click here to see the XYZ CARGO ADD-ON Project.

Cycle Training and Mechanical Contracts available dependant on location. Please Contact Us with your needs and we can try to make it happen.
